Sprinter XL

Automazione rapida e affidabile per l'immunofluorescenza indiretta

IF Sprinter di Euroimmun offre una soluzione flessibile per la completa automazione dei test in immunofluorescenza nei laboratori piccoli e medi: il dispositivo esegue in autonomia le diverse fasi, dall’identificazione, diluizione e dispensazione dei campioni, fino all’incubazione e lavaggio dei vetrini.

  • Sistema flessibile per la piena automazione dei test IFA ed ELISA in un solo strumento

  • Affidabilità e tracciabilità garantite dal lettore di codici a barre integrato per l'identificazione automatica del campione e l'identificazione automatica dei vetrini tramite i codici matrix (opzionale)

  • Pipettamento efficace senza contaminazioni garantito da quattro puntali lavabili, due bracci robotici indipendente e il calcolo ottimale del flusso di lavoro

  • Operazioni semplificate per la gestione giornaliera dei laboratori, grazie al sistema intuitivo di comunicazione con il LIS o EUROLabOffice

  • Configurazione variabile a seconda delle esigenze del laboratorio, con la capacità di gestire fino a 240 campioni e fino a 30 vetrini nella stessa seduta

Workflow optimisation

  • 45 sample and reagent tracks for freely flexible loading
  • Slides with 10 and 50 reaction fields
  • Spatial separation of liquid handling and incubation (enables parallel workflows)
  • Fully automated washing and mounting of slides

Precise and efficient pipetting

  • 10 coated stainless steel needles and precision pumps for high pipetting accuracy
  • Optimised pipetting efficiency due to economical routes
  • Secure pipetting procedure owing to liquid level detection
  • Multishot function for the dispensing of reagents and samples

Innovative washing technology

  • Fully automated washing of IFA slides using directed and controlled liquid flow: MERGITE! washing technology
  • Two integrated washing units for slides with 10 and 50 reaction fields
  • Integrated washing unit for cleaning of reagent trays
  • Automatic dispensing of mounting medium

Convenient operation

  • Touch-screen PC with intuitive graphic user interface
  • Clear display of the time schedule for the current run
  • Software-supported maintenance with minimum time required

Overview of the process status

  • Convenient system overview with detailed status information on run times, resources and slides
  • ID-based memory function for dilution plates
  • Exact time information on pending actions to improved plannability

Process security from A-Z

  • Software access with different user accounts and rights
  • Transparent traceability of all data entries and changes
  • Gapless allocation of test results to the samples and reagents used

Tipi di campionesiero, plasma e liquido cefalorachidiano
Numero max. di campioni
gestiti
fino a 240 campioni
Capacità del vetrinofino a 30 vetrini (possono essere combinati vetrini con 10 e 50 pozzetti)
ProvetteDiametro esterno 10 – 16 mm, altezza fino a 100 mm
Volume di pipettamento5 μl – 1000 μl, 1 μl incrementale
Tracciabilitàregistrazione automatica dei campioni, registrazione automatica dei vetrini (opzionale)
Ingombro (LxLxH)1190 mm x 850 mm x 710 mm
Peso150 kg
